16. When a small amount of solid sodium hydroxide is added to a sample of dilute hydrochloric acid, an exothermic reaction takes place.
The following graph shows the temperature of the acid during the reaction. The cooling of the solution after the initial reaction follows an approximately linear trend, as indicated by the dotted line.
What value for the temperature change, ΔT, should be used to calculate the change in energy, q, during the reaction? q=mcΔT
C
Explanation:
The graph shows that the maximum change in temperature is 24.9−20.0=4.9°C. However, extrapolating the linear cooling trend to the time of addition gives a theoretical maximum change of 5.4°C. This is the value of ΔT that should be used to obtain the best estimate of q, as the extrapolation accounts for heat loss to the environment during the reaction.
The other distractors correspond to the temperature change at the latest recorded time point (option A) and the extrapolated temperature change at time = 0ss (option D), a time point which precedes the addition of the solid and is therefore irrelevant.
This question is moderately difficult as the student must interpret a graph and apply the heat loss correction with little guidance.
